Roller P8x11.8
- Brand: Mortch Motor
- Product Code: MICF30410-00800
- Product Viewed: 7
- Availability: In Stock
- Weight: 0.01kg
US$0.15
| Shipping To： |
🔧 CFMoto Dowel Pin
📦 Part Number: 30410-00800
⚙️ Dowel Pin / Roller Pin · P8x11.8 · OEM Specification
📍 Installation Position: Engine Case Mating Surface / Cylinder Alignment / Component Positioning
✅ Precision Manufactured · Wear Resistant · Fits Multiple CFMoto Engine Series
This product is a CFMoto OEM-spec dowel pin (roller pin), part number 30410-00800, size P8x11.8 (8mm diameter × 11.8mm length). Dowel pins are critical alignment components used during engine assembly, installed at the mating surfaces between crankcase halves, cylinder block, cylinder head, and other components. They ensure precise alignment between parts, prevent relative movement, and guarantee assembly accuracy and sealing effectiveness.
Dowel pins are easily lost, damaged, or deformed during engine disassembly and reassembly. Timely replacement of missing or damaged dowel pins is essential to maintain engine assembly precision and prevent oil or compression leaks.
✅ Genuine Quality Assurance: Manufactured strictly to CFMoto original technical standards. Dimensional accuracy and material hardness are identical to the original part for perfect fitment.
This dowel pin (30410-00800 / P8x11.8) fits the following CFMoto engines and models:
- 172MM-2 (2017-2019) · 250cc
- 172MM-2A (2023-2025) · 250cc (CF250-11)
- 172MM-2C (2022-2026) · 250cc (CF250-7-EU5 / CHAMPION VERSION)
- 172MM-2D (2026) · 250cc
- 172MM-3 (2024-2025) · 250cc
- 178MN (2020) · 300cc
- 178MN-A (2021-2024) · 300cc
- 178MN-F (2023-2026) · 300cc
- 272MQ-B (2024-2026)
- 272MQ-D (2023-2026) · 400-10H
- 272MQ-F (2022-2026) · CHAMPION VERSION (2025)
- 372MT-F (2025)
- 372MT-H (2025)
- 380Y-2A (2025) · Z10
- 380Y-2C (2026)
- 380Y-3 (2025-2026) · UForce 1000 XL
- CF250-A / CF250-A(EU4) · 250NK (2018-2020)
- CF250-F(EU5) · 250 Series (2021)
- CF300 / CF300-US · 300NK (2019-2025)
- CF300-3(EU4) / CF300-3F(EU5) · 300SR (2020-2022)
- CF300-7F · 300CL‑X (2022-2023)
- CF300-BF(EU5) · 300 Series (2022)
- CF300-F(EU5) · 300 Series (2021)
- CF400-6F(EU5) · 400 Series (2023)
📌 Fitment Note: This dowel pin fits the CFMoto engine series listed above (172MM, 178MN, 272MQ, 372MT, 380Y, etc.) and the motorcycles equipped with these engines. Dowel pins are standard components shared across multiple engine types. If your specific model is not listed, please contact customer service with your VIN for confirmation.
- ✅ OEM Specification: Manufactured strictly to CFMoto original technical standards; dimensional accuracy identical to the original part.
- 🛡️ Precision Outer Diameter: Outer diameter is precision ground for tight fit with locating holes, ensuring accurate alignment.
- 💪 High-Quality Material: Made from high-quality carbon structural steel or bearing steel for wear resistance and dimensional stability.
- 🔧 Direct Replacement: Directly replaces lost, damaged, or deformed original dowel pins.
- ⚡ Ensures Assembly Accuracy: Proper installation of dowel pins guarantees precise alignment of crankcase halves, cylinders, and other components.
• Original dowel pins lost during engine disassembly and repair.
• Dowel pins are rusted, deformed, or damaged.
• Loose fit in mounting holes causing poor alignment.
• Replacing crankcase, cylinder block, cylinder head, or other major components requires new dowel pins.
• Always use new dowel pins during engine overhaul to ensure assembly precision.
If any of these conditions occur, replace the dowel pins promptly.
1. Clean the dowel pin holes thoroughly before installation, removing oil and debris.
2. Inspect the dowel pin holes for burrs or damage; repair if necessary.
3. Gently tap or press the dowel pin into the hole, ensuring it is fully seated.
4. The dowel pin should protrude slightly above the mating surface for proper alignment.
5. When joining components, ensure dowel pins correctly enter the corresponding holes before tightening bolts.
6. It is recommended to replace dowel pins with new ones after each engine disassembly for optimal alignment accuracy.
Professional installation is recommended.
