Piston Pin
- Brand: Mortch Motor
- Product Code: MICF0GRV-040020-5000
- Product Viewed: 41
- Availability: In Stock
- Weight: 0.09kg
US$2.00
| Shipping To： |
🔧 CFMoto Piston Pin
📦 Part Number: 0GRV-040020-5000
⚙️ Piston Pin · Wrist Pin · OEM Spec
📍 Installation: Piston-to-connecting rod connection
✅ Single unit · Premium alloy steel · OEM specification · Fits multiple CFMoto ATV models
This is a CFMoto OEM-spec piston pin, part number 0GRV-040020-5000, sold as a single unit. The piston pin is the connecting component between the piston and connecting rod, transferring the reciprocating motion of the piston to the connecting rod, which then drives the crankshaft — a critical link in the engine's power transmission chain.
The piston pin is subjected to high-intensity alternating loads and impacts. Over time, it may develop play, noise, or even fracture due to wear, fatigue, or poor lubrication — affecting engine operation and reliability. Replacing it promptly with an OEM-spec pin is essential to restore engine performance and ensure operational safety.
✅ OEM Quality Assurance: Manufactured to CFMoto's original technical standards using premium alloy steel with precision machining and heat treatment. Dimensions and surface finish are identical to genuine parts, ensuring a perfect replacement and reliable connection performance.
This piston pin (part number 0GRV-040020-5000, single unit) fits the following CFMoto ATV models:
- CF400ATR-7L · CForce C4 Touring T3b (2026)
- CF400ATR-7S · CForce C4 (2026)
- CF400AZ-17S · CForce C4 (2026)
- CF400AZ-7L · CForce C4 (2027)
- CF400AZ-7S · CForce C4 (2026)
- CF500ATR-15L · GOES TERROX 550L T3b (2026)
- CF500ATR-17L · GOES TERROX 500L EPS T3b (2026)
- CF500AZ-17L · CForce C5 Touring (2026-2027)
- CF500AZ-17S · CForce C5 (2026)
📌 Fitment Note: This piston pin is designed for CFMoto ATV models equipped with 192Q or 192R engines. Single unit. If your specific model is not listed, please contact us with your VIN to confirm compatibility.
- ✅ OEM Specification: Manufactured to CFMoto's original technical standards. Dimensions and surface finish are identical to genuine parts.
- 🛡️ Premium Alloy Steel: Made from high-strength alloy steel with heat treatment and precision machining for excellent wear and fatigue resistance.
- 🔧 Precision Machining: Precision-ground outer diameter and end faces for perfect fitment with the piston and connecting rod.
- 💪 Reliable Connection: Effectively transfers power between the piston and connecting rod, ensuring proper engine operation.
- 🔄 Direct Replacement: Can be used to directly replace worn or damaged original piston pins.
• Unusual engine noise (knocking or clicking).
• Excessive play or movement at the piston-to-rod connection.
• Inspection reveals wear, scoring, or discoloration (overheating) on the pin.
• Circlip is damaged or missing.
• Loss of engine power accompanied by abnormal vibration.
If any of these signs appear, please inspect and replace the piston pin promptly.
1. Confirm the piston pin part number is 0GRV-040020-5000 and matches your vehicle.
2. Remove the piston assembly and extract the old piston pin.
3. Clean the piston pin bore and connecting rod small end, removing oil and debris.
4. Check the clearance between the pin and piston/rod to ensure it meets specifications.
5. When installing the new pin, apply lubrication and use a proper press tool.
6. Install the circlips and ensure they are fully seated in the grooves.
7. Check that the pin rotates freely with no binding.
Professional installation is recommended. Maintain cleanliness to prevent contaminants from entering the mating surfaces.
- Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
- We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
- Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
- Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
- All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
- In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.
