C4/C5 Cylinder Gasket
- Brand: Mortch Motor
- Product Code: MICF0GRV-02310A
- Product Viewed: 31
- Availability: In Stock
- Weight: 0.05kg
US$5.19
-
- 10 or more US$4.15
| Shipping To： |
🔧 CFMoto Cylinder Gasket Set
📦 Included Parts: Cylinder Head Gasket · Cylinder Body Gasket
⚙️ Cylinder Gasket Set · Engine Seal Gasket · OEM Spec
📍 Installation: Between cylinder head & cylinder · Between cylinder & crankcase
✅ Complete set with 2 parts · OEM specification · Fits CFMoto CForce C4/C5 & GOES TERROX models
📌 Note: This cylinder gasket set includes the 2 parts listed above (1 cylinder head gasket + 1 cylinder body gasket), providing a complete sealing solution for engine overhaul.
This is a CFMoto OEM-spec cylinder gasket set, including cylinder head gasket (1 pc) and cylinder body gasket (1 pc) — 2 pieces in total. This gasket set is a critical component of the engine sealing system, installed between the cylinder head and cylinder, and between the cylinder and crankcase, to seal the combustion chamber, oil galleries, and coolant passages — preventing gas, oil, and coolant leaks.
Cylinder gaskets are subjected to high temperatures, high pressures, and thermal cycling. They may fail due to aging, fatigue, or damage — resulting in power loss, oil emulsification, coolant consumption, or white exhaust smoke. Replacing with an OEM-spec gasket set ensures the engine regains reliable sealing and extends its service life.
✅ OEM Quality Assurance: Manufactured to CFMoto's original technical standards using premium high-temperature sealing materials. Dimensions and thickness are identical to genuine parts, ensuring a perfect replacement and reliable sealing performance.
This cylinder gasket set fits the following CFMoto ATV models:
- CF400ATR-7L · CForce C4 Touring T3b (2026) · Engine 192Q
- CF400ATR-7S · CForce C4 (2026) · Engine 192Q
- CF400AZ-17S · CForce C4 (2026) · Engine 192Q
- CF400AZ-7L · CForce C4 (2027) · Engine 192Q
- CF400AZ-7S · CForce C4 (2026) · Engine 192Q
- CF500ATR-15L · GOES TERROX 550L T3b (2026) · Engine 192R
- CF500ATR-17L · GOES TERROX 500L EPS T3b (2026) · Engine 192R
- CF500AZ-17L · CForce C5 Touring (2026-2027) · Engine 192R
- CF500AZ-17S · CForce C5 (2026) · Engine 192R
📌 Fitment Note: This cylinder gasket set is designed for CFMoto CForce C4/C5 series and GOES TERROX models equipped with 192Q or 192R engines. If your specific model is not listed, please contact us with your VIN to confirm compatibility.
- ✅ OEM Specification: Manufactured to CFMoto's original technical standards. Material, dimensions, and thickness are identical to genuine parts.
- 🛡️ Complete Set: Includes both cylinder head gasket and cylinder body gasket — all essential parts in one package.
- 🔧 Premium Sealing Material: Made from high-temperature, oil-resistant, coolant-resistant sealing material for long-term reliability.
- 💪 Reliable Sealing: Effectively seals combustion chamber, oil, and coolant passages — preventing leaks.
- 🔄 Direct Replacement: Can be used to directly replace aged, damaged, or failed original cylinder gaskets.
• Loss of engine power, poor acceleration.
• Abnormal coolant consumption — radiator level keeps dropping.
• Oil emulsification (milky white foam in oil).
• White smoke from exhaust (coolant entering combustion chamber).
• Engine overheating with abnormal temperature rise.
• Visible oil stains or coolant seepage at cylinder/head joint.
If any of these signs appear, please inspect and replace the cylinder gasket set promptly.
1. Remove the cylinder head and cylinder, clean off old gasket residue.
2. Clean sealing surfaces — ensure they are free of oil, debris, and scratches.
3. Inspect cylinder head and cylinder flatness; resurface if necessary.
4. Install the new cylinder body gasket (between cylinder and crankcase).
5. Install the new cylinder head gasket (between cylinder head and cylinder).
6. Torque cylinder head bolts to specification in the correct sequence.
7. Refill coolant and oil, start the engine, and check for leaks.
Professional installation is recommended. Always follow factory torque specifications and tightening sequence.
- Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
- We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
- Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
- Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
- All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
- In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.
