This is a specially made Variator locking tool for blocking the variator on engines during assembly and dismantling.
Easy handling makes work fast and professional. The tool is simply placed over the teeth of the Kickstarter carrier and fixed into the two long holes with a screw or bolt on the engine housing. The variator nut can then be easily secured or loosened.
Peugeot variator locking tool which is compatible with
-
APRILIA MOJITO CUSTOM 50 with PIAGGIO MOTOR
-
APRILIA SR 50 DITECH 2003>2004 PIAGGIO MOTOR
-
APRILIA SR 50 LC 2003>2004 PIAGGIO CARB MOTOR
-
APRILIA SR 50 R CARB MODEL 2005 on
-
APRILIA SR 50 R FACTORY INJECTION 2005 on
-
APRILIA SR MOTARD 50
-
DERBI GP1 50 2001>2005
-
DERBI GP1 50 2005 on
-
GILERA DNA 50
-
GILERA ICE
-
GILERA RUNNER 50 2006 on
-
GILERA RUNNER 50 and 50 SP upto 2006
-
GILERA SKP 50 and STALKER 50
-
ITALJET JETSET 50
-
ITALJET TORPEDO 50 2002 on PIAGGIO MOTOR
-
PIAGGIO DIESIS 50
-
PIAGGIO FLY 50 2 STROKE
-
PIAGGIO FLY 50 4 STROKE
-
PIAGGIO FREE 50
-
PIAGGIO LIBERTY 50 1996>2004
-
PIAGGIO LIBERTY 50 2004 on
-
PIAGGIO NRG EXTREME AIR COOLED
-
PIAGGIO NRG EXTREME LC
-
PIAGGIO NRG MC2
-
PIAGGIO NRG MC3 AIR COOLED
-
PIAGGIO NRG MC3 LC
-
PIAGGIO NRG MC3 PURE JET
-
PIAGGIO NRG POWER AIR COOLED
-
PIAGGIO NRG POWER LC
-
PIAGGIO QUARTZ 50
-
PIAGGIO SFERA 50 RST with DISC FRONT BRAKE
-
PIAGGIO SFERA 50 with DRUM FRONT BRAKE
-
PIAGGIO SFERA 80 with DRUM FRONT BRAKE
-
PIAGGIO SKIPPER 80 and SKR 80
-
PIAGGIO TYPHOON 50
-
PIAGGIO TYPHOON 50 2011 on
-
PIAGGIO TYPHOON 80
-
PIAGGIO ZIP 50 1991>1994
-
PIAGGIO ZIP 50 1994>1999
-
PIAGGIO ZIP 50 2000 on
-
PIAGGIO ZIP SP 50 1996>1999
-
PIAGGIO ZIP SP 50 2001 ON
-
VESPA ET2 50
-
VESPA LX 50 2 STROKE and LXV 50 2 STROKE
-
VESPA S 50 2 STROKE
Hole distance: 91mm
Mortch Motor parts supported the Brands of
BAOTIAN, BASHAN, BENZHOU, CFMOTOR, CHARMING, DAYANG, DINLI, FUXIN, GEELY, GILERA, HANGLONG, HAOJIN, HAOJUE, HISUN, HONGZHOU, HUATIAN, JIAJUE, JIANSHE, JINLUN, JMSTAR, JONWAY, KAITONG, KEEWAY, KINROAD, KYMCO, LIFAN, LINGBEN, LINGTIAN, LINHAI, LINTEX, LONCIN, LONGJIA, MAWI, MEIDUO, MOTORRO, PIAGGIO, QINGQI, RHON, RIEJU, SACHS, SHINERAY, SKYGO, SUKIDA, TAOTAO, VESPA, VONROAD, WANGYE, WONJAN, XINGYUE, XINLING, XINTIAN, YIBEN, YINGANG, ZHONGYU, ZNEN, ZONGSHEN, etc.
Note:
1. Please make sure this parts fits your particular model. Many bikes have the same name but use different parts depending on the year of manufacture.
2. The photos and measurements are for your reference only, and the goods is subject to the real product which you will receive.
3. Import duties, taxes and other customs related charges are not included. Buyers bear all responsibility for all extra charges incurred (if any).
