CF Moto listed parts number is 0180-023100 with old part number listed as CF188-023100, Marked with 493cm3
- CF188-023100 0180-023100 Cylinder, Marked with 493cm3
- CF188-040003 0180-040003-0050 Clip, Piston Pin
- CF188-040002 0180-040002 Piston Pin
- CF188-040004 0180-040004 Piston
- CF188-0400A0 0180-0400A0 Piston Ring
Linhai listed parts number is
- 35119 1BE-11310-00 Cylinder 1 PCs
- 35129 1BE-11634-00 Clip, Piston Pin 2 PCs
- 35128 1BE-11633-00 Piston Pin 1 PCs
- 35127 1BE-11631-00 Piston 1 PCs
- 35124 1BE-11611-00 Top Ring 1 PCs
- 35125 1BE-11612-00 2Nd Ring 1 PCs
- 35126 1BE-11613-00 Oil Ring 1 PCs
- Diameter of the Kit(mm): 87.5
- Displacement: 500cc
- Outer Diameter of Cylinder Skirt(mm): 93.5
- Middle Height of Cylinder(mm): 100
- Total Height of Cylinder(mm): 139.5
This may fits
- ATV CF500 X5 CF188
- ATV CF500-2 X5 CF188
- ATV CF500-2A X5 CF188
- ATV CF500-5 X5 CF188
- ATV CF500-5A X5 CF188
- ATV CF500-5B X5 CF188-B
- ATV CF500-5C X5 CF188-B
- ATV CF500-A X5 CF188
- ATV CF500-B X5 CF188
- ATV CF500-C X5 CF188
- ATV CF500-D X5 CF188
- ATV CF500-E X5 CF188
- UTV CF500-3 UForce 500 U5 CF188-A
Mortch Motor parts supported the Brands of
BAOTIAN, BASHAN, BENZHOU, CFMOTOR, CHARMING, DAYANG, DINLI, FUXIN, GEELY, GILERA, HANGLONG, HAOJIN, HAOJUE, HISUN, HONGZHOU, HUATIAN, JIAJUE, JIANSHE, JINLUN, JMSTAR, JONWAY, KAITONG, KEEWAY, KINROAD, KYMCO, LIFAN, LINGBEN, LINGTIAN, LINHAI, LINTEX, LONCIN, LONGJIA, MAWI, MEIDUO, MOTORRO, PIAGGIO, QINGQI, RHON, RIEJU, SACHS, SHINERAY, SKYGO, SUKIDA, TAOTAO, VESPA, VONROAD, WANGYE, WONJAN, XINGYUE, XINLING, XINTIAN, YIBEN, YINGANG, ZHONGYU, ZNEN, ZONGSHEN, etc.
Note:
1. Please make sure this parts fits your particular model. Many bikes have the same name but use different parts depending on the year of manufacture.
2. The photos and measurements are for your reference only, and the goods is subject to the real product which you will receive.
3. Import duties, taxes and other customs related charges are not included. Buyers bear all responsibility for all extra charges incurred (if any).
