Cylinder Block

CF Moto listed part number is 0600-023100 with old part number listed as 196S-023100, Marked with 594cm3

  • Diameter of the Kit: 96mm
  • Displacement: 600cc
  • Outer Diameter of Cylinder Skirt: 103.5mm
  • Middle Height of Cylinder: 100mm
  • Total Height of Cylinder: 139.5mm

This may fits

  • ENGINE  2011  196S-B(U6)  600cc
  • ENGINE  2012  196S-B(U6)  600cc
  • ENGINE  2013  196S-B(U6)  600cc
  • ENGINE  2014  196S-B(U6)  600cc
  • ENGINE  2015  196S-B(U6)  600cc
  • ENGINE  2010  196S-B(X6)  600cc
  • ENGINE  2011  196S-B(X6)  600cc
  • ENGINE  2012  196S-B(X6)  600cc
  • ENGINE  2013  196S-B(X6)  600cc
  • ENGINE  2014  196S-B(X6)  600cc
  • ENGINE  2015  196S-B(X6)  600cc
  • ENGINE  2016  196S-B(X6)  600cc
  • ENGINE  2017  196S-B(X6)  600cc
  • ENGINE  2010  196S-C  Z6 600cc
  • ENGINE  2011  196S-C  Z6 600cc
  • ENGINE  2012  196S-C  Z6 600cc
  • ENGINE  2013  196S-C  Z6 600cc
  • ENGINE  2014  196S-C  Z6 600cc
  • ENGINE  2015  196S-C  Z6 600cc
  • ENGINE  2016  196S-C  Z6 600cc
  • ENGINE  2017  196S-C  Z6 600cc
Mortch Motor parts supported the Brands of BAOTIAN, BASHAN, BENZHOU, CFMOTOR, CHARMING, DAYANG, DINLI, FUXIN, GEELY, GILERA, HANGLONG, HAOJIN, HAOJUE, HISUN, HONGZHOU, HUATIAN, JIAJUE, JIANSHE, JINLUN, JMSTAR, JONWAY, KAITONG, KEEWAY, KINROAD, KYMCO, LIFAN, LINGBEN, LINGTIAN, LINHAI, LINTEX, LONCIN, LONGJIA, MAWI, MEIDUO, MOTORRO, PIAGGIO, QINGQI, RHON, RIEJU, SACHS, SHINERAY, SKYGO, SUKIDA, TAOTAO, VESPA, VONROAD, WANGYE, WONJAN, XINGYUE, XINLING, XINTIAN, YIBEN, YINGANG, ZHONGYU, ZNEN, ZONGSHEN, etc.
Note:
1. Please make sure this parts fits your particular model. Many bikes have the same name but use different parts depending on the year of manufacture.
2. The photos and measurements are for your reference only, and the goods is subject to the real product which you will receive.
3. Import duties, taxes and other customs related charges are not included. Buyers bear all responsibility for all extra charges incurred (if any).
    Product QR Code
  • Brand: Mortch Motor
  • Product Code: MICF0600-023100
  • Product Viewed: 7737
  • Availability: In Stock
  • Weight: 3.50kg
  • $112.73
